radiant WNRL50WH Smart Tru-Universal Dimmer 120V 700W Forward Reverse Phase White Polycarbonate Satin
Documents
Sell Sheet
Brochure
Downloads
Installation Instructions
Instruction Sheet
Supporting Document
The radiant® Smart Tru-Universal Dimmer with Netatmo is designed to elevate your home lighting experience with smart functionality and versatile control. This dimmer offers seamless integration with various smart home devices, compatible with Amazon Alexa, Google Assistant, and Apple HomeKit, allowing you to manage your lighting from your smartphone or tablet. With the ability to work with virtually any 120V dimmable bulb or fixture, it ensures robust performance in a variety of settings, whether for casual evenings or vibrant gatherings. Additionally, the included screwless wall plate contributes to a sophisticated aesthetic, perfectly complementing other designer switches and outlets in the radiant® Collection. The dimmer not only enhances your lifestyle with features like customizable schedules, energy monitoring, and scene settings but also promises reliability through its dedicated mesh-network connection, facilitated by a Smart Gateway. Easy to install in place of an existing switch, this dimmer is a great addition to any residential or commercial space, combining form, function, and modern technology.
- UL Listed, cULus Listed, FCC and RoHS compliant for safety and environmental standards
- Ultra-reliable performance through a dedicated mesh-network via Smart Gateway
- Works with virtually any 120V dimmable bulb or fixture (excludes 0-10V)
- Controls and dims lights via smartphones and tablets with Legrand Home + Control app
- Supports forward or reverse phase dimming for versatile compatibility
- Easy installation replacing existing switch with neutral wire required
- Includes screwless wall plate for a sleek, sophisticated designer look
- Compatible with Amazon Alexa, Google Assistant, and Apple HomeKit for smart home integration
- Customizable schedules, groups, scenes, and energy monitoring capabilities
- Suitable for residential, commercial, and multi-dwelling applications
- Load Rating: 120V 700W (Incandescent, Halogen - Forward Phase Only), 120V 450W 3.8A (LED, EFL, CFL - Forward Phase Only), 120V 500VA (MLV - Forward Phase Only), 120V 250W 2.1A (CFL, ELV - Reverse Phase Only), 120V 450W (Incandescent, Halogen - Reverse Phase Only), 120V 450W 3.8A (LED - Reverse Phase Only)
- Voltage: 120 V AC
- Amperage: 2.1A to 3.8A depending on load and phase
- Frequency Rating: 60 Hz
- Load Type: Incandescent, Halogen, ELV, MLV, LED, CFL, EFL, Fluorescent
- Switch Type: Paddle
- Number of Switches: 1
- Number of Poles: Multi-Location, Single Pole 3-Way
- Wire Size: #14 - #10 AWG
- Number of Wires: 4
- Requires Neutral Wire: Yes
- Mounting Type: Wall Box
- Wire Connection Type: Flying Leads
- Dimming Compatibility: Forward or Reverse Selectable Phase
- Product Width: 1.73 in
- Product Height: 4.19 in
- Product Length: 1.53 in
- Material: Polycarbonate
- Finish: Satin
- Color: White
- Compliance: UL Listed, cULus Listed, FCC Compliant, RoHS Compliant, IC Certified
- Country of Origin: China
