radiant RHCL453PTCCCV6 Dimmer 120V 700W Single Pole 3-Way Locator Light Thermoplastic Satin Ivory Light Almond White

Experience versatile lighting control with the radiant® CFL/LED Dimmer, a sophisticated solution for both single-pole and 3-way applications. Crafted from durable, high-impact resistant thermoplastic, this dimmer is not only cULus and UL Listed for safety but also allows users to seamlessly replace any basic switch or dimmer while accommodating a wide range of dimmable bulb types, including LEDs, CFLs, and incandescent options. Its unique adjustment dial enhances compatibility with various bulbs, providing a customizable dimming range that suits your preferences. A low-profile paddle switch ensures smooth on/off operation, while an ergonomic slider allows for precise light level adjustments. Designed with convenience in mind, the constant memory feature restores lighting to your desired level after a power outage, and the innovative locator light softly glows in the dark, making it easy to find the switch. Available in multiple color finishes to complement your decor, this dimmer not only enhances functionality but also contributes to the aesthetic appeal of your space, particularly when paired with a sleek, screwless radiant® Wall Plate.

• cULus and UL Listed for safety assurance
• Compatible with dimmable CFL, LED, incandescent, and halogen bulbs
• Replaces basic switches or dimmers in single-pole and 3-way applications
• No neutral wire required for installation
• High-impact resistant thermoplastic construction for durability
• Low-profile paddle switch for smooth on/off control
• Ergonomic slider allows precise light level adjustments
• Constant memory restores previous light level after power outages
• Locator light softly glows for easy identification in the dark
• Adjustment dial customizes dimming range for varied bulb types

• Load Rating: 120V 450W (CFL), 120V 450W (LED), 120V 700W (Incandescent), 120V 700W (Halogen)
• Voltage: 120 VAC
• Frequency: 60 Hz
• Dimming Compatibility: Forward Phase
• Number of Poles: Single Pole, 3-Way
• Wire Size: #14 - #10 AWG
• Requires Neutral Wire: No
• Mounting Type: Wall Box
• Wire Connection Type: Screw Terminals
• Dimensions: 1.75 in (W) x 1.25 in (D) x 4.25 in (H)
• Material: Steel, Thermoplastic
• Finish: Satin
• Indoor/Outdoor: Indoor
• Load Type: Incandescent, Halogen, LED, CFL
• Maximum Humidity: 95% (relative humidity, non-condensing)
• Color: Ivory, Light Almond, White
• Country of Origin: China
• Preset: Yes
• Number of Switches: 1
• Switch Type: Slider, Paddle
• Product Line: Pass & Seymour
• Application Sector: Residential
