radiant R26USBCC6W USB Outlet 15A Tamper-Resistant 2-Port USB-C Satin White
Specifications
Documents
Sell Sheet
Supporting Document
Downloads
White Papers & Tech Bulletins
Installation Instructions
Upgrade your charging capabilities with this innovative USB outlet, which seamlessly replaces traditional outlets in as little as ten minutes. Designed with convenience in mind, it features two USB Type-C connections, delivering an impressive 6.0 amps to ensure speedy charging for your latest mobile devices, all without the need for bulky adapters. Safety is prioritized with a patented tamper-resistant shutter system that not only protects children but also maintains a sleek and unobtrusive appearance thanks to its "invisi-shutters." This versatile outlet is perfect for both residential and hospitality applications, enhancing any space with its modern, satin white finish. Additionally, its compatibility with other designer switches and outlets from the radiant® Collection allows for a cohesive look throughout your interiors. With a limited lifetime warranty, you can trust this reliable charging station to provide convenience and safety for years to come.
- Tamper-resistant shutter system for child safety
- UL and cULus Listed for safety compliance
- Two USB Type-C ports delivering 6.0 amps for fast charging
- Smart Chip technology maximizing USB charging speed
- Back and side wire termination with internal pressure plates for secure connections
- Durable polycarbonate face and nylon back body materials
- Satin white finish enhancing residential and hospitality interiors
- Compatible with radiant® Collection designer switches and outlets
- Quick replacement of traditional outlets in about ten minutes
- Operates reliably in up to 95% relative humidity, non-condensing environments
- Voltage: 5.0 V
- Amperage: 15.0 A
- USB Amperage: 6.0 A total
- USB Wattage: 15.0 W
- Power: 30 W
- Outlet Type: Tamper-Resistant USB-Charging
- Mounting Type: Box
- Connection Location: Back and Side
- Wire Connection Type: Internal Pressure Plates
- Dimensions: 4.18 in x 1.693 in x 1.35 in
- Number of Poles: Double Pole
- Number of Receptacles: 2
- Number of USBs: 2
- Material Face: Polycarbonate
- Material Back Body: Nylon
- Material Line Contacts: CDA 260 Brass
- Material Mounting Strap: .049 inch Zinc-Plated Steel
- Material Terminal Screws: Zinc-Plated Steel
- Material Ground Screw: Steel with Green Chromate
- Operating Temperature: -40°C to +60°C
- Compliance: UL Listed, cULus Listed
- Color: White
- Finish: Satin
- Indoor/Outdoor: Indoor
- Country of Origin: China
- Application Sector: Residential, Hospitality, Multi-Dwelling Unit
- Environmental Conditions: 95% relative humidity, non-condensing
- Product Line: Pass & Seymour
- Warranty Type: Limited Lifetime Warranty
