Pass & Seymour R26USBAC6W USB Charger Outlet 6.0A Type-A Type-C Tamper-Resistant White Polycarbonate Lexan

Enhancing convenience and safety for modern users, this innovative charger combines a 6.0A Ultra-Fast Type-A/C USB charger with a duplex tamper-resistant outlet. With industry-leading performance, you can charge smartphones, tablets, and laptops up to 40% faster compared to standard USB chargers, thanks to Smart Chip technology that optimizes charging speed for each port. The thoughtfully designed scalloped cover and user-friendly installation features, such as external brass backwire pressure-plates and posted side-wire terminal screws, streamline the setup process, making it suitable for both professionals and DIY enthusiasts. Safety is paramount, as the patented shutter system with discreet "invisi-shutters" effectively prevents improper insertion of foreign objects, making it ideal for environments with children. Additionally, its compliance with various safety standards and RoHS guidelines ensures environmentally-friendly use. This USB outlet is not just a practical addition to your space but a forward-thinking solution that addresses the power needs of today’s tech-savvy households.

• Duplex tamper-resistant outlet enhances child safety
• Patented "invisi-shutters" prevent foreign object insertion
• 6.0A ultra-fast charging for smartphones, tablets, and laptops
• Smart Chip technology maximizes charge speeds per USB port
• Reversible Type-C USB connector supports latest devices
• External brass backwire pressure-plates ensure secure wiring
• Posted side-wire terminal screws simplify installation
• Scalloped cover design improves aesthetics and installation
• Back and side wire terminals accept #10-#14 AWG wire for flexibility
• Complies with cULus, UL Listed, CSA, and RoHS safety standards

• Voltage: 125 V
• Amperage: 6.0 A Total (Type-A: 2.4 A; Type-C: 3.0 A)
• Torque: 12-14 lb.-in
• Width: 1.74 in.
• Height: 2.69 in.
• Depth: 1.67 in.
• Material: Polycarbonate Lexan
• Compliance: cULus, UL Listed (E140596), CSA Listed, RoHS Compliant
• NEMA Configuration Number: 5-15R
• USB Configuration: (1) Type-A; (1) Type-C
• Color: White
• Country of Origin: China
