Mulberry Metal Products 30274 Weatherproof Take-Off Extension 1/2 in Hub Size 4 Hubs 10 Cubic Inch Die-Cast Aluminum Gray Powder Coated

Engineered for versatility and durability, the weatherproof take-off extension from Mulberry Metal Products provides an efficient solution for electrical installations in a variety of environments. Constructed from rugged die-cast aluminum, its robust design is complemented by a superior powder-coated finish that not only resists scratches but also ensures maximum weatherability, making it ideal for dry, damp, and wet locations alike. With the ability to add take-offs in four different directions thanks to its threaded outlet on the side, this extension is both functional and convenient. Included with the product are two close-up plugs, a gasket, and mounting screws, allowing for straightforward installation. Additionally, this extension features four hubs with a hub size of 1/2 inch, catering to various electrical configurations while maintaining the highest standards of safety with UL approval for both Canada and the US.

• UL listed for safety assurance in Canada and the US
• Weatherproof design suitable for dry, damp, and wet locations
• Rugged die-cast aluminum construction for durability
• Superior powder-coated finish for scratch and weather resistance
• Four threaded 1/2 inch hubs, two per end
• Allows take-offs in four different directions for flexible wiring
• Includes two close-up plugs, gasket, and mounting screws for easy installation
• Flanged design extends box depth and wiring capacity
• Made in USA for quality assurance

• Capacity: 10 Cubic Inch
• Hub Size: 1/2 Inch
• Hub Location: 2 per end
• Number of Hubs: 4
• Depth: 1.375 Inch
• Mounting: Screw
• Material: 0.094 Inch Thick Die-Cast Aluminum
• Finish: Powder Coated Painted
• Color: Gray
• Approval: UL (Canada and US)
• Type: Flanged
• Application: Dry, damp, wet locations
• Country of Origin: USA
