Mulberry Metal Products 30269 Weatherproof Outlet Box 2-Gang 7 Hub 1/2 Inch Die-Cast Aluminum Gray Powder Coated

Offering a blend of durability and versatility, this weatherproof outlet box is built from rugged die-cast aluminum to withstand the elements while ensuring reliable power access in both indoor and outdoor locations. Its NEMA 3R rating guarantees protection against rain and moisture, making it ideal for damp or wet environments. Features such as permanently attached lugs that rotate for flexible mounting, reinforced mounting straps for optimal security, and a superior powder coat finish enhance its performance by providing maximum weatherability and scratch resistance. Moreover, it comes complete with detachable mounting lugs, closure plugs, and a self-tapping ground screw for easy installation, making it a robust choice for any electrical project.

• NEMA 3R rated for rain and moisture protection
• Rugged die-cast aluminum construction for durability in harsh environments
• Superior powder coat finish for maximum weatherability and scratch resistance
• Reinforced mounting straps enhancing stability and security
• Permanently attached lugs that rotate for mounting versatility
• Includes detachable mounting lugs, closure plugs, and self-tapping ground screw for easy installation
• Seven 1/2 inch threaded hubs providing versatile wiring access
• Compact 2-gang design for indoor and outdoor electrical applications
• Made in USA ensuring quality and compliance

• Capacity: 30.5 cu in
• Number of Hubs: 7 threaded
• Hub Size: 1/2 in
• Number of Gangs: 2
• Height: 4.5 in
• Width: 4.5 in
• Depth: 2 in
• Material: Die-cast aluminum, 0.094 in thick
• Finish: Powder Coated
• Hub Location: (1) Back, (3) Each End
• Mounting Hardware: Lug, Self-Tapping Ground Screw, (2) Close-Up Plug
• Approval: UL (Canada and US), c-UL-us, NEMA 3R Rated
• Color: Gray
• Country of Origin: USA
