Mulberry Metal Products 30267 Weatherproof Box 30.5 cu in 2 Gang NEMA 3R Die-Cast Aluminum Gray

This weatherproof box from Mulberry Metal Products is engineered for excellence, making it a reliable choice for various environmental conditions. Constructed from heavy-duty die-cast aluminum, it provides enhanced durability and features a superior powder coat finish that ensures both maximum weatherability and scratch resistance. Rated NEMA 3R, this enclosure is suitable for dry, damp, or wet locations, making it versatile for diverse applications. In addition, the design includes practical components such as a detachable lug, a self-tapping ground screw, and two closure plugs, enhancing usability while meeting ARRA compliance standards. With a capacity of 30.5 cubic inches and multiple hub options for easy installation, this enclosure is not only functional but also built to last in the demanding conditions typical in industrial environments.

• NEMA 3R rated for dry, damp, and wet locations
• Heavy-duty die-cast aluminum construction for durability
• Superior powder coat finish for weatherability and scratch resistance
• Includes detachable mounting lug and self-tapping ground screw
• Three 1-inch threaded hubs at back and ends for versatile wiring access
• 30.5 cubic inch capacity accommodates multiple devices
• Complies with UL and c-UL safety standards for US and Canada
• ARRA compliant for regulatory standards
• Manufactured in the USA for quality assurance

• Capacity: 30.5 Cubic Inch
• Hub Size: 1 Inch
• Depth: 2 Inch
• Height: 4.5 in
• Width: 4.5 in
• Number of Gangs: 2
• Number of Hubs: 3
• Hub Location: (1) Back, (1) Each End
• Material: 0.094 Inch Thick Heavy Duty Die-Cast Aluminum
• Finish: Powder Coated Painted
• Mounting Hardware: Lug
• Approval: UL (Canada and US), c-UL-us
• Enclosure Rating: NEMA 3R
• Color: Gray
• Country of Origin: USA
