Mulberry Metal Products 12805 Conduit Body LB 1-1/2 in Threaded 90 Degree 2 Hubs Aluminum Electrostatic Powder Coated

Designed to facilitate efficient management of conduit installations, this conduit body is perfect for making 90-degree bends in conduit runs while ensuring the integrity and safety of electrical systems. Constructed from high-strength, corrosion and weather-resistant aluminum alloy, it guarantees long-lasting durability, and it features a smooth, tapered NPT threaded hub for reliable connections. The flat back design allows for easy mounting close to walls, ensuring that this conduit body can be integrated seamlessly into any project. With an internal volume of 33.8 cubic inches, it provides ample space for wiring, enabling easy access during wire pulling, splicing, or maintenance activities. Equipped with a neoprene rubber gasket and approved by UL and CSA standards, this conduit body meets stringent safety and quality requirements, fulfilling the needs for both rigid conduit and EMT installations. Whether you're working on new construction or upgrades, this product balances functionality and robust design, simplifying the way you manage electrical conduits.

• UL and CSA listed for safety compliance
• Neoprene rubber gasket ensures effective sealing
• High-strength, corrosion, and weather resistant aluminum alloy
• Electrostatic powder coated die-cast aluminum for durability
• Smooth, tapered NPT threaded hubs for reliable connections
• Two hubs positioned at 90 degrees for conduit routing
• Flat back design allows easy mounting close to walls
• Internal volume of 33.8 cubic inches provides ample wiring space
• Galvanized steel cover offers robust protection
• Compatible with IMC and rigid conduit systems

• Approval: UL, UL 514A, CSA C22.2
• Hub Size: 1-1/2 Inch
• Configuration: LB
• Installation: Threaded
• Size: 2.48 in Length x 7.75 in Width x 3.68 in Height
• Material: Electrostatic Powder Coated Die-Cast Aluminum
• Cover Type: Galvanized Steel
• Used On: IMC/Rigid Conduit
• Hub Location: 90 Degree
• Number of Hubs: 2
• Access Opening: Back
• Internal Volume: 33.8 cubic inches
• Maximum Wire Size: 3 #1/0 AWG
