Cutler-Hammer H2008B-3 Freedom Definite Purpose Heater Pack 32-75A Overload Relay 3.23-5.23A Class 20
Developed by Cutler-Hammer, the Freedom/Definite Purpose Heater Pack is engineered to ensure optimal performance and reliability for various industrial applications. Designed to meet both NEMA and IEC standards, its versatility allows it to be used with a range of starter sizes, enhancing its applicability across different systems. The pack features an overload relay with options of 32 or 75A, catering to a full load current range from 3.23A to 5.23A, which can be easily adjusted via its dial positions. This unit employs a standard trip mechanism classified as Class 20, making it an essential component for protecting machinery from overload conditions. With heater packs shipped three to a carton, this product is not only practical but also efficient for contractors and technicians seeking dependable thermal protection solutions for starters across various sizes.
- UL Listed and CSA Certified for safety assurance
- Standard trip mechanism with Class 20 rating for reliable overload protection
- Adjustable full load current range from 3.23A to 5.23A via dial settings
- Overload relay options of 32A or 75A to suit protection needs
- Meets NEMA and IEC design standards for broad compatibility
- Compatible with a wide range of starter sizes across Series B and C and IEC sizes
- Designed for Freedom/Definite Purpose applications in industrial motor control
- Full Load Current Range: 3.23A, 3.9A, 4.56A, 5.23A (Dial positions A, B, C, D)
- Overload Relay: 32A or 75A
- Trip Type: Standard Trip, Class 20
- Design: NEMA, IEC
- Special Features: Compatible with starter sizes 00-0 (Series C), 1-2, 5-8 (Series B), IEC Sizes A-F (Series C), G-K (Series B), P-X, Z
- Type: Freedom/Definite Purpose Heater Pack
- Compliance: UL Listed, CSA Certified
