Cutler-Hammer GHB3070 Molded Case Circuit Breaker 70A 480Y/277 Vac Three-Pole 65 kAIC G-frame
The Eaton Series C complete molded case circuit breaker by Cutler-Hammer is engineered for optimal protection in both commercial and industrial applications. With a robust amperage rating of 70A and a trip type that includes fixed thermal and fixed magnetic options, this breaker ensures reliable operation across various conditions. It can handle a voltage rating of 480Y/277 Vac and 125/250 Vdc, making it versatile enough for different electrical systems. Designed as a three-pole configuration, it supports an interrupt rating of 65 kAIC at 240 Vac, ensuring safety in the event of electrical faults. Its compact G-frame design, with dimensions that include a length of 2.63 inches, width of 3 inches, and height of 4 inches, allows for easy integration into panels while maintaining efficiency in space utilization.
- UL Listed for assured safety compliance
- Provides reliable protection with fixed thermal and magnetic trip mechanisms
- High interrupt rating of 65 kAIC at 240 Vac for fault safety
- Compatible with both AC and DC voltage systems (480Y/277 Vac, 125/250 Vdc)
- Supports three-pole configuration for balanced electrical control
- Rated for 70A amperage suitable for commercial and industrial use
- Operates at standard 50/60 Hz frequency for versatile applications
- Compact G-frame design for efficient panel space utilization
- Complete breaker assembly for straightforward installation
- Amperage: 70A
- Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
- Voltage Rating: 480Y/277 Vac, 125/250 Vdc
- Frequency Rating: 50/60 Hz
- Trip Type: Fixed thermal, fixed magnetic
- Circuit Breaker Type: GHB
- Type: Molded case circuit breaker
- Circuit Breaker Frame Type: Complete breaker
- Number of Poles: Three-pole
- Frame Size: G-frame
- Length: 2.63 in
- Width: 3 in
- Height: 4 in
- Weight: 1.75 lb
- Series: Series C
- Compliance: UL Listed
