Cutler-Hammer GHB3040 Molded Case Circuit Breaker 40A 480Y/277 Vac Three-Pole G-frame
Engineered for optimal stability and robust electrical protection, this molded case circuit breaker is part of the Eaton Series C lineup by Cutler-Hammer. Designed to handle a voltage rating of 480Y/277 Vac and 125/250 Vdc, it provides reliable performance across various applications. With a fixed thermal and magnetic trip type, this three-pole G-frame model ensures efficient operation, safeguarding circuits with an interrupt rating of 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac. Compact and efficient, its dimensions make it suitable for installations where space is a premium, making it an essential component for modern electrical systems.
- UL Listed for recognized safety and performance standards
- Fixed thermal and magnetic trip ensures reliable circuit safeguarding
- High interrupt rating of 65 kAIC at 240 Vac for enhanced fault interruption
- Three-pole design for multi-phase circuit protection
- Supports wide voltage range of 480Y/277 Vac and 125/250 Vdc for versatile applications
- Compact G-frame size suitable for space-constrained installations
- Complete breaker design simplifies installation and integration
- Operates at 50/60 Hz frequency rating for broad compatibility
- Engineered for optimal stability and robust electrical protection
- Compliant with federal specifications W-C375B for quality assurance
- Amperage: 40A
- Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
- Voltage Rating: 480Y/277 Vac, 125/250 Vdc
- Number of Poles: Three-pole
- Trip Type: Fixed thermal, fixed magnetic
- Frequency Rating: 50/60 Hz
- Length: 2.63 in
- Width: 3 in
- Height: 4 in
- Weight: 1.75 lb
- Circuit Breaker Type: GHB
- Type: Molded case circuit breaker
- Circuit Breaker Frame Type: Complete breaker
- Frame Size: G-frame
- Series: Series C
- Compliance: UL Listed
- Product Compliance: Federal Specifications Classification W-C375B
