Cutler-Hammer GHB1030 Molded Case Circuit Breaker 30A Single-Pole 14 kAIC 277 Vac G-frame
The Eaton Series C complete molded case circuit breaker from Cutler-Hammer is engineered to provide dependable protection and performance in various electrical systems. This single-pole circuit breaker features a fixed thermal and magnetic trip type that ensures effective interruption of current, safeguarding your electrical components against overload and short circuit conditions. With an interrupt rating of 14 kAIC at 277 Vac, it is adept at handling demanding applications up to 30A, making it suitable for a range of residential and commercial uses. Designed with a compact G-frame size, this circuit breaker not only optimizes space but also delivers reliable operation at voltage ratings of 277 Vac and 125 Vdc, making it an essential component for modern electrical installations.
- Fixed thermal and magnetic trip for reliable overload and short circuit protection
- High interrupt rating of 14 kAIC at 277 Vac for enhanced safety in demanding applications
- UL Listed for assured safety and performance
- Single-pole design suitable for residential and commercial electrical systems
- Dual voltage rating of 277 Vac and 125 Vdc for versatile electrical compatibility
- Compact G-frame size optimizes installation space
- Complete molded case breaker design for integrated protection and easy installation
- Operates at standard 50/60 Hz frequency for broad electrical system compatibility
- Type: Molded case circuit breaker
- Amperage Rating: 30A
- Interrupt Rating: 14 kAIC at 277 Vac
- Number Of Poles: Single-pole
- Voltage Rating: 277 Vac, 125 Vdc
- Trip Type: Fixed thermal, fixed magnetic
- Circuit Breaker Type: GHB
- Circuit Breaker Frame Type: Complete breaker
- Frame Size: G-frame
- Series: Series C
- Frequency Rating: 50/60 Hz
- Height: 4 IN
- Length: 2.63 IN
- Width: 1 IN
- Weight: .65 LB
