Cutler-Hammer EHD3060 Molded Case Circuit Breaker 60A Three-pole Fixed Thermal Magnetic 18 kAIC 240V F-frame
Engineered for robust performance, this complete molded case circuit breaker from Cutler-Hammer ensures reliable electrical protection for a variety of applications. With a three-pole design and a fixed thermal and magnetic trip type, it provides effective circuit interruption at an impressive interrupt rating of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac. This EHD-series model is rated for 60 Amperes and designed to fit F-frame applications, accommodating the demands of both commercial and industrial environments while operating efficiently at a frequency of 50/60 Hz. Compact yet powerful, this circuit breaker is an essential component for maintaining a safe and efficient electrical system.
- UL Listed for verified safety and compliance
- High interrupt rating of 18 kAIC at 240 Vac for enhanced safety
- Fixed thermal and magnetic trip type for reliable fault interruption
- Three-pole design for balanced circuit protection
- Rated for 60A to support medium power circuits
- Complete molded case breaker for robust and compact installation
- F-frame size fitting standard commercial and industrial applications
- Operates efficiently at 50/60 Hz frequency
- Load side terminals for ease of wiring and connection
- Amperage Rating: 60A
- Interrupt Rating: 18 kAIC at 240 Vac, 14 kAIC at 480 Vac
- Number of Poles: Three-pole
- Trip Type: Fixed thermal, fixed magnetic
- Circuit Breaker Type: EHD
- Circuit Breaker Frame Type: Complete breaker
- Frame Size: F-frame
- Frequency Rating: 50/60 Hz
- Height: 6 in
- Length: 3.38 in
- Width: 4.13 in
- Weight: 4.5 lb
- Terminals: Load side
- Series: Series C
