Cutler-Hammer DPU222R Air Conditioning Disconnect Non-fused Pullout 60A 120/240V 10 hp NEMA 3R Galvanized Steel ANSI 61 gray
This reliable Air Conditioning Disconnect from Cutler-Hammer is designed to ensure safe and efficient operation of HVAC systems. Its non-fused pullout type construction allows for easy access while maintaining essential protection, with a robust amperage rating of 60A and an interrupt rating of 10 kAIC for enhanced safety. Constructed from galvanized steel and housed in a NEMA 3R enclosure, it offers durability and resilience against the elements, making it suitable for outdoor applications. With a voltage rating of 120/240V and compatibility with wire sizes up to #14-3 AWG, this disconnect is not only practical but supports up to 10 horsepower at 240V for demanding installations, embodying both reliability and versatility in one compact unit.
- Non-fused pullout design for easy and safe disconnection
- Interrupt rating of 10 kAIC for enhanced electrical safety
- Rated for 60A amperage supporting high electrical load
- Supports up to 10 hp at 240V for demanding HVAC applications
- Compatible with #14-3 AWG copper/aluminum wiring
- Durable galvanized steel construction resists corrosion
- NEMA 3R enclosure providing weather and outdoor protection
- Compact size for convenient installation in tight spaces
- CSA Certified and UL Listed for reliable safety compliance
- Amperage: 60A
- Horsepower: 10 hp at 240 V
- Interrupt Rating: 10 kAIC
- Voltage: 120/240V
- Height: 2 in
- Length: 9 in
- Width: 5.5 in
- Weight: 3 lb
- Type: Non-fused pullout
- Material: Galvanized steel
- Enclosure: NEMA 3R
- Wire Size: #14-3 AWG Cu/Al
- Color: ANSI 61 gray
- Compliance: CSA Certified, UL Listed
