Cutler-Hammer BR3040L200R Loadcenter 200A 120/240V 40-Circuit Single-Phase NEMA 3R Metallic
Engineered for robust performance, the BR style 1-inch loadcenter by Cutler-Hammer is an ideal solution for managing electrical distribution in residential or commercial settings. With a substantial amperage rating of 200A and a voltage rating of 120/240V, it is designed to accommodate up to 40 circuits within a compact enclosure featuring a metallic construction. This loadcenter supports Type BR 1-inch breakers and comes with built-in provisions for a hold-down kit, ensuring reliable circuit management while promoting safety with its 25 kAIC interrupt rating. The NEMA 3R enclosure is suitable for various environments, making it a versatile addition to any electrical system.
- Includes cover for safety and dust protection
- 25 kAIC interrupt rating for high fault current capacity
- 200A amperage rating for heavy electrical loads
- NEMA 3R enclosure for outdoor protection
- Aluminum bus material for corrosion resistance
- No feed-thru lugs for streamlined wiring
- Supports up to 40 circuits with 30 available spaces
- Compatible with Type BR 1-inch breakers
- Single-phase design suitable for residential use
- Notch for brhdk125 hold-down kit for secure installation
Specifications
- Length: 5.19 IN
- Interrupt Rating: 25 kAIC
- Used With: Type BR 1-inch breakers
- Box Size: D1r
- Main Circuit Breaker: BWH
- Notes: Has notch for brhdk125 hold-down kit.
- Number Of Circuits: 40
- Number Of Spaces: 30
- Wire Size: #1 AWG-300 kcmil Cu/Al
- Amperage Rating: 200A
- Enclosure: NEMA 3R
- Width: 14.31 IN
- Voltage Rating: 120/240V
- Special Features: No feed-thru lugs
- Cover: Cover included
- Enclosure Material: Metallic
- Weight: 43 LB
- Phase: Single-phase
- Bus Material: Aluminum
- Number Of Wires: Three-wire
- Height: 29.13 IN
- Type: Main lug
