Cutler-Hammer BQC230240 Four-Pole Plug-on Breaker 120/240V 10 kAIC Rejection Tab
The Type BQC 1-inch CTL Plug-on Breaker from Cutler-Hammer is engineered to ensure robust protection and reliability for electrical systems. This four-pole breaker is compatible with Type BR loadcenters and is designed with an interrupt rating of 10 kAIC, making it suitable for various applications. With the added convenience of a Rejection Tab feature, it prevents incorrect installation, enhancing both safety and ease of use. Its voltage rating of 120/240V and capability to accommodate wire sizes from #14 to 4 AWG Cu/Al further consolidate its versatility, making it a dependable choice for both residential and commercial electrical setups.
- Rejection Tab feature to prevent incorrect installation
- 10 kAIC interrupt rating for reliable fault current interruption
- Four-pole design for comprehensive circuit protection
- Common trip type for simultaneous pole switching
- Compatible with Type BR loadcenters for versatile use
- Supports #14 to 4 AWG Cu/Al wire sizes for flexible wiring
- Plug-on mounting for quick and secure installation
- 120/240V voltage rating suitable for residential and commercial applications
- Amperage: (1) Two-Pole 30A, (1) Two-Pole 40A
- Interrupt Rating: 10 kAIC
- Voltage: 120/240V
- Number of Poles: Four-pole
- Trip Type: Common
- Wire Size: #14-4 AWG Cu/Al
- Mounting: Plug-on
- Type: Type BQC 1-inch CTL Plug-on Breaker
- Used With: Type BR Loadcenters
- Main Circuit Breaker: BQC
- Special Features: Includes Rejection Tab feature
