Cutler-Hammer BQC220230 Four-pole Plug-on Breaker 20A 30A 120/240V 10 kAIC Rejection Tab
Designed for seamless integration with Type BR loadcenters, the Type BQC 1-inch CTL Plug-on Breaker from Cutler-Hammer offers a robust solution for circuit protection. This four-pole breaker is equipped with a unique arrangement featuring (1) two-pole 20A and (1) two-pole 30A amperage ratings, making it versatile for various electrical needs. With a voltage rating of 120/240V, it supports wire sizes ranging from #14 to 4 AWG in both copper and aluminum, ensuring compatibility for a broad spectrum of installations. The breaker’s 10 kAIC interrupt rating provides reliable overcurrent protection, while its common trip type enhances safety by allowing all poles to trip simultaneously under fault conditions. Notably, the inclusion of a Rejection Tab feature adds an extra layer of security, preventing improper installation. This thoughtfully engineered component not only meets stringent industry standards but also simplifies the installation process, making it an essential choice for professionals in the field.
- Common trip ensures all poles trip simultaneously enhancing safety
- 10 kAIC interrupt capacity for reliable overcurrent protection
- Combination of two-pole 20A and two-pole 30A breakers for versatile circuit protection
- Supports 120/240V voltage rating for broad application
- Supports #14-4 AWG copper and aluminum wires for wide compatibility
- Four-pole design for multi-circuit protection
- Compatible with Type BR loadcenters for seamless integration
- Plug-on mounting for easy installation
- Rejection tab prevents improper installation
- Amperage: (1) Two-Pole 20A, (1) Two-Pole 30A
- Voltage Rating: 120/240V
- Interrupt Rating: 10 kAIC
- Number of Poles: Four-pole
- Type: Type BQC 1-inch CTL Plug-on Breaker
- Mounting: Plug-on
- Trip Type: Common
- Wire Size: #14-4 AWG Cu/Al
- Used With: Type BR Loadcenters
- Special Features: Includes Rejection Tab feature
