C2G 50634 High Speed HDMI Cable 35 ft 23 AWG CL2 Rated Black PVC
Documents
Elevate your audiovisual experience with this C2G 35ft Select High Speed HDMI® Cable featuring an in-wall, CL2-rated jacket, designed to ensure safe and effective performance in residential and commercial settings alike. Capable of supporting all HDMI 1.4 features, it delivers stunning video resolutions up to 4K (4096 x 2160 at 30Hz), making it ideal for high-definition gaming and streaming. The cable is equipped with gold-plated connectors, enhancing its durability and ensuring a reliable connection with low signal loss. Whether you're setting up a home theater or a commercial presentation, this cable’s exceptional data transfer rate of 10.2 Gbps guarantees seamless transmission, allowing you to enjoy your media like never before.
- In-wall CL2-rated jacket for safe residential and commercial use
- Supports all HDMI 1.4 features including 4K (4096 x 2160 at 30Hz, 4:4:4) resolution
- Gold plated connectors for enhanced durability and reliable connections
- High speed data transfer rate of 10.2 Gbps for seamless media transmission
- Foamed PE and HDPE insulation for signal integrity and reduced interference
- Aluminum foil and Mylar shielding with 60% braided coverage for EMI/RFI reduction
- PVC jacket with CMG rating and UL/CL2 compliance for robust protection
- Flexible cable design with 100mm bend radius for easy installation
- 19-pin HDMI connectors compatible with standard HDMI devices
- CMG jacket with CE approval for additional safety assurance
- Resolution Support: Up to 4K (4096 x 2160 at 30Hz, 4:4:4)
- Data Transfer Rate: 10.2 Gbps
- Cable Length: 35 ft (10.7 m)
- Bend Radius: 70 mm
- Wire Gauge: 23 AWG Bare Copper
- Jacket Rating: CL2 Rated, FT4 Rated
- Jacket Material: PVC (Polyvinyl Chloride)
- Application Sector: Residential, Commercial
- Cable Type: High Speed HDMI, Video
- Color: Black
- Country of Origin: Vietnam
- Connector Type: 19 pin HDMI
- Nominal Impedance: 100 Ω
- Nominal Capacitance: 95.2 pF/m
- Dielectric Strength: 2.1
- Insulation Resistance: 10 MΩ
- Cable Bend Radius: 100 mm
- Conductor Type: 23 AWG Bare Copper, 28 AWG Bare Copper
- Insulation Type: Foamed PE, HDPE
- Shield Material: Aluminum Foil + Mylar, 25% min overlapped, 60% braided coverage
- Connector Plating: Gold Plated
- Jacket Material Detail: CMG (PVC, UL/CL2), Black, O.D. 10.0 ± 0.2 mm
- Approvals: CMG, CE
Cutsheet
CG-50634 CutsheetDownloads
