C2G 41414 Active HDMI Cable 35 ft 4K 60Hz 18 Gbps CL3 Rated Black PVC
Documents
Elevate your audio and visual experience with this 35ft Active High Speed HDMI® Cable, expertly designed to support resolutions up to 4K (4096 x 2160 at 60Hz) for crystal-clear video quality. It boasts impressive data transfer speeds of up to 18 Gbps, ensuring that even the most demanding content, including full HD Blu-ray and HD DVD video, is transmitted without lag or loss of fidelity. The specification also accommodates a remarkable 32 audio channels and supports high-resolution audio formats such as DTS-HD Master Audio™ and Dolby TrueHD™, making it an excellent choice for home theaters and commercial installations alike. With a CL3-rated jacket, this cable is suitable for in-wall installations, providing flexibility and safety in any setup. The durable PVC jacket and 26 AWG wire gauge ensure reliability and longevity, while added features like Consumer Electronics Control (CEC) commands and the Audio Return Channel (ARC) maintain the functionality and convenience you expect from modern HDMI connectivity. Whether you are enhancing residential entertainment systems or upgrading commercial setups, this 35ft HDMI cable is engineered to deliver an exceptional audio-visual experience.
- CL3-rated jacket for safe in-wall installation
- Supports high-resolution 4K (4096 x 2160 at 60Hz 4:4:4) video
- Data transfer speeds up to 18 Gbps for high-bandwidth content
- Supports up to 32 audio channels with 1536 kHz sampling rate
- Compatible with DTS-HD Master Audio™ and Dolby TrueHD™ formats
- Supports 8, 10, 12, and 16 bit per channel Deep Color
- Includes Consumer Electronics Control (CEC) and Audio Return Channel (ARC)
- Durable PVC jacket for long-lasting protection and flexibility
- Shield coverage of 65% reduces electromagnetic interference
- Flexible design with 200 mm minimum bend radius for easier installation
- Resolution: 4K (4096 x 2160) at 60Hz 4:4:4
- Data Transfer Rate: 18 Gbps
- Audio Channels: 32 channels
- Audio Sampling Rate: 1536 kHz
- Deep Color Support: 8, 10, 12, 16 bit per channel
- Length: 35 ft (10.7 m)
- Wire Gauge: 26 AWG
- Minimum Bend Radius: 200 mm
- Jacket Rating: CL3 Rated, FT4 Rated
- Jacket Material: PVC (Polyvinyl Chloride)
- Color: Black
- Country of Origin: China
- Cable Type: High Speed HDMI, Video
- Type: Cable, Active Device
- Application Sector: Residential, Commercial
- Shield Coverage: 65%
- Drain Wire AWG: 28 AWG & 7/0.127 TC
- Cable Construction: E352299 Type CL3 75C 24 AWG
- Insulation Resistance Test: 10 Ohm, 300V DC
- Operating Temperature: 0C to +50C
- Storage Temperature: -25C to +85C
