C2G 00937 Ethernet Patch Cable 0.5 ft 24 AWG Snagless Orange PVC
Specifications
Application Sector
Commercial / Residential
Color
Orange
Voltage
30 V
Wire Connection Location
8p8c (rj45)
Wire Size
24 AWG
Documents
Enhancing your network connectivity, this Ethernet patch cable from C2G is designed for high performance and reliability. Measuring 0.5 feet in length, it is constructed with 24 AWG wires and equipped with standard RJ45 connectors, ensuring seamless connections across residential, commercial, and industrial applications. The snagless design not only protects the clips during frequent plug and unplug actions, but it also maintains the neatness of your setup. With a vibrant orange PVC jacket, this cable is not only durable but makes it easy to color-code your network for better organization. Perfect for a variety of uses, it combines practicality with a standout design, catering to the needs of modern network environments.
- Snagless design protects connector clips during plug/unplug
- PVC jacket provides durable and flexible cable protection
- Bright orange PVC jacket for easy network color-coding
- Constructed with 24 AWG wires for reliable signal transmission
- Standard 8P8C (RJ45) connectors ensure industry compatibility
- Unshielded twisted pair (UTP) cable designed for data networking
- Meets CE compliance for safety and quality assurance
- Suitable for residential, commercial, and industrial applications
- Supports voice, data, and video distribution up to 350 MHz
- Cable Length: 0.5 ft
- Wire Gauge: 24 AWG
- Voltage Rating: 30V
- Temperature Rating: 60 °C
- Impedance: 100 Ω
- Conductor DC Resistance: 9.38 Ω/100m (maximum)
- Capacitance: 5600 pF/100m
- Propagation Delay: 545 ns/100m (maximum)
- Delay Skew: 45 ns/100m (maximum)
- Jacket Material: PVC (Polyvinyl Chloride)
- Jacket Rating: Standard / Non-Rated
- Cable Type: Ethernet Patch Cable, Booted, Snagless, Unshielded (UTP)
- Color: Orange
- Country of Origin: Vietnam
- Application Sector: Residential, Commercial, Industrial
- Connector Type: 8P8C (RJ45)
- Compliance: CE
Downloads
Cat5e Snagless Unshielded (UTP) Ethernet Network Patch CableCat5e Snagless Unshielded Cables 2Cutsheet
CG-00937 Cutsheet
