Bryant GFRST15I GFCI Receptacle 15A 125V 5-15R AUTOGUARD Self-Test Ivory
Specifications
Amperage
15 A
Color
Ivory, Ivory
Contact Material
Brass
Material
Nylon
Mounting Screw Material
Zinc Plated Steel
NEMA Configuration
5-15R
Number Of Wires
3-Wire Grounding
Number of Poles
2-Pole
Product Type
Standard
Style
Standard
Voltage
125 V
Documents
Sales Drawings
Specs
Catalog Page
Installation/Instruction Manual (IOM)
Engineering Drawing
The Specification Grade GFRST15I from Bryant is engineered for excellence in electrical installations, featuring a robust standard design that meets all NEC® requirements. Its patented AUTOGUARD® self-test technology enhances safety by ensuring reliability through consistent performance checks. This heavy-duty outlet offers a secure and efficient termination process, thanks to the internal back wiring clamp and guide that streamline installation. With a current rating of 15 amps and a voltage rating of 125 volts, it is perfect for a wide array of applications, all while showcasing a classic ivory finish that fits seamlessly into any space.
- Patented AUTOGUARD® self-test technology for enhanced safety
- Internal back wiring clamp and guide for quick and secure termination
- Heavy-duty design suitable for commercial and specification grade use
- Complies with NEC®, UL, CSA, ADA, and NEMA WD-6 standards
- Brass power and ground contacts for corrosion resistance and durability
- Nylon face and base materials providing impact resistance and longevity
- Zinc plated steel mounting strap and screws for rust protection
- 15A, 125V rating suitable for a wide range of electrical applications
- 2-pole, 3-wire grounding configuration for secure electrical connections
- Classic ivory finish for seamless interior integration
- Amperage: 15 A
- Voltage: 125 V
- NEMA Rating: 5-15R
- Poles: 2-Pole
- Wires: 3-Wire Grounding
- Type: Standard
- Style: Standard
- Series: Heavy Duty
- Color: Ivory
- Material Face: Nylon
- Material Base: Nylon
- Material Power Contacts: Brass
- Material Ground Contacts: Brass
- Material Mounting Strap: Zinc Plated Steel
- Material Mounting Screws: Zinc Plated Steel
- Compliance: UL Listed, CSA Certified, NEC Compliant, ADA Compliant, NEMA WD-6 Compliant
