Anamet Electrical 39461 Liquid-Tight Flexible Metal Conduit Type EF 2 in Gray PVC Jacket

Optimized for versatility and reliability, this liquid-tight flexible metal conduit provides essential wiring protection for various general construction applications. Manufactured with a smooth jacket, it not only looks good but is designed to endure temperatures ranging from -4°F to +176°F, making it suitable for a wide array of environments. Available in trade sizes from 3/8" to 2", its compatibility with standard liquid-tight connectors facilitates effortless installation, and it achieves an IP 67 rating when properly paired with approved connectors. Whether you’re working on a residential project or a commercial endeavor, this conduit ensures that electrical conductors are securely housed, providing peace of mind in performance and safety.

• Provides liquid-tight raceway for secure wiring protection
• Rated IP67 for liquid protection with approved connectors
• Compatible with standard liquid-tight connectors for easy installation
• Smooth appearing PVC jacket for exposed applications
• Temperature resistant from -4°F to +140°F (-20°C to +60°C)
• Constructed with hot dipped zinc galvanized steel core for durability
• Designed for general construction grade applications
• Compliant with RoHS and WEEE environmental standards

• Type: EF
• Electrical Trade Size: 2 in (53 mm)
• Length: 50 ft (15.24 m)
• Inside Diameter: 2.020 to 2.045 in (51.308 to 51.943 mm)
• Outside Diameter: 2.340 to 2.375 in (59.436 to 60.325 mm)
• Approx. Inside Bend Radius: 7.0 in (177.8 mm)
• Approx. Weight per 100 ft: 120 lbs (54.43 kg)
• Material: Hot dipped zinc galvanized steel, PVC jacket
• Temperature Range: -4°F to +140°F (-20°C to +60°C)
• Ingress Rating: IP67
• Certifications: RoHS, WEEE
• Color: Gray
• Cross-Reference #: 80162, EF-16, EFLT-2, EXLT-2
