ABB THQL1140 Circuit Breaker 1 Pole 40A 120/240V 10kA Q-Line Plug-In
Specifications
American Recovery and Reinvestment Act (ARRA) Compliant
Contact Manufacturer
Amperage Rating
40 A
Application
Thermal Magnetic
Brand Name
Q-Line (Plug-In)
Buy American Act (BAA) Compliant
Contact Manufacturer
Frame
Q-Line
Interrupt Rating
10 kA @ 120 Vac / 10 kA @ 120/240 Vac
Load Rating
HACR
Number Of Poles
Single Pole
Standard
UL Listed (E11592)
Sub Brand
Q Line
Trip Range
Non-Interchangeable
Trip Type
LI
Voltage Rating
240 V
Engineered for robust performance, the THQL 1 POLE 120/240V circuit breaker from ABB offers reliable thermal magnetic protection tailored for diverse applications. With a significant amperage rating of 40 amps and an interrupt rating of 10kA at both 120VAC and 240VAC, it ensures safety and efficiency in managing electrical loads. This breaker, a part of the Q-Line series, boasts a convenient plug-in design that simplifies installation in panel setups. It adheres to stringent standards for quality and compliance, making it a dependable choice for both residential and commercial settings.
